Спецификации
- Суич, типFixed Port
- Общ брой портове28
- Основни портове, тип24x10GE SFP
- Power Over Ethernet (PoE)No
- Uplink портове4x10GBase-T
- Свободни (10GB) слотовеNo
- УправлениеWeb-based GUI; D-Link Network Assistant Utility; Full CLI; Telnet Server; TFTP Client; Configurable MDI/MDIX; SNMP (Supports v1/v2c/v3); SNMP Trap; Smart Wizard; LLDP; LLDP-MED; BootP/DHCP Client; RMON v1/v2; Dual Images; Dual Configurations; DNS Client
- StackableNo
- Fans2 x Smart Fan
- ЗахранванеAC Input: 100 to 240 VAC, Max Power Consumption: 85.7 W
- RoutingLayer 3 Lite
- Памет (Flash, RAM)-
- Капацитет за маршрутизиране/превключване, Gbps560 Gbps
- Пропускателна способност, Mpps416.64 Mpps
- MAC адреси32000 MAC address table size
- VLAN (брой, стандарти)802.1Q VLAN, Port-based VLAN, Configurable VID: 1~4094, Voice VLAN, Auto Surveillance VLAN, Asymmetric VLAN, 4K VLAN Groups
- QoS802.1p; 8 queues per port; Queue Handling - Strict Priority Que (SPQ), Weighted Round Robin (WRR); Bandwidth Control - Port-based (Ingress/Egress, min. granularity 64 Kbps), Queue-based (Egress, min. granularity 64 Kbps)
- L2 мрежови стандартиIEEE 802.3u, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3an, IEEE 802.3ae, IEEE 802.3z, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1X
- L3 мрежови стандартиDefault Route, Static Route: Max. 128 IPv4 entries, Max. 64 IPv6 entries
- IPv6 functionalityIPv6 Traffic Class, IPv6 Flow Label/Traffic Class, IPv6 Neighbor Discovery (ND), IPv6 ND Inspection, IPv6 Route Advertisement (RA) Guard
- СигурностBroadcast/Multicast/Unicast Storm Control; D-Link Safeguard Engine; DHCP Server Screening; IP-MAC-Port Binding; Traffic Segmentation; SSH; SSL (Support TLS 1.0/1.1/1.2, Support IPv4/IPv6); DoS Attack Prevention; Port Security; Duplicate Address Detection
- Размери (Ш, Д, В), mm441 x 209.5 x 44 mm
- Опция за монтажRackmount
- ДругиRJ45 console port, Auto MDI/MDIX adjustment for all twisted-pair ports
- Гаранция, м.99 месеца
- Тегло, кг.4.43 кг.
