Задължителен е минимум 3-годишен лиценз DNA Essentials!
Спецификации
- Суич, типFixed Port
- Общ брой портове24
- Основни портове, тип24x10/100/1000Base-T
- Power Over Ethernet (PoE)IEEE 802.3at PoE+ (up to 30W per port), Perpetual PoE, Fast PoE; Available PoE Power: 370W* (Default primary power supply - PWR-C5-600WAC), 740W* (Optional secondary power supply - PWR-C5-600WAC), *Limited by port number and port rating
- Uplink портове0
- Свободни (10GB) слотовеModular uplink options (C9200-NM-4G, C9200-NM-4X)
- УправлениеSNMPv1, SNMPv2c, and SNMPv3; RMON I and II standards; Internet Group Management Protocol (IGMP); CLI; TCP; UDP
- StackableCisco StackWise-160 stacking ports: copper-based Cisco StackWise cabling, Stacking hardware (C9200-STACK-KIT=), Supported stack members: Other C9200 models with same license level (8 Number of members)
- FansField-Replaceable Units (FRU) redundant
- ЗахранванеDual field-replaceable power supplies, Default primary AC power supply: PWR-C5-600WAC
- RoutingLayer 3 Advanced
- Памет (Flash, RAM)Flash memory: 4 GB; RAM: 4 GB DRAM
- Капацитет за маршрутизиране/превключване, Gbps128 Gbps
- Пропускателна способност, Mpps190.4 Mpps
- MAC адреси32000 MAC address
- VLAN (брой, стандарти)VLAN IDs: 4096; IEEE 802.1Q VLAN
- QoSGranular wireless bandwidth management and fair sharing,802.1p Class of Service (CoS) and Differentiated Services Code Point (DSCP) field classification,Shaped Round Robin (SRR) scheduling,Committed Information Rate (CIR), and eight egress queues per port
- L2 мрежови стандартиIEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3bz, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.1x-Rev, IEEE 802.3x
- L3 мрежови стандартиIP unicast routing protocols: Static, Routing Information Protocol Version 1 [RIPv1], and RIPv2, RIPng, Open Shortest Path First [OSPF]
- IPv6 functionalityIPv6 routing (using OSPFv3 and EIGRPv6) is supported in hardware for maximum performance; IPv6 addressing is supported on interfaces with appropriate show commands for monitoring and troubleshooting
- СигурностEnhanced security with AES-128 MACsec encryption, policy-based segmentation, and trustworthy systems
- Размери (Ш, Д, В), mm445 x 350 x 44
- Опция за монтажRackmount
- ДругиЗадължителен е минимум 3-годишен лиценз DNA Essentials.
- Гаранция, м.99 месеца
- Тегло, кг.6 кг.
