D-Link 10G Layer 3 Stackable Managed Switches

D-Link 10G Layer 3 Stackable Managed Switches - 0

D-Link 10G Layer 3 Stackable Managed Switches - 1

D-Link 10G Layer 3 Stackable Managed Switches - 2

D-Link 10G Layer 3 Stackable Managed Switches - 3

Спецификации

Суич, тип
Fixed Port
Общ брой портове
32
Основни портове, тип
28x10GE SFP
Power Over Ethernet (PoE)
No
Uplink портове
4x10G/25G SFP28
Свободни (10GB) слотове
No
Управление
Web-based GUI, CLI, Telnet Server/Client, TFTP Client, DNS Client, SNMP (Supports v1/v2c/v3), SNMP Traps, sFlow, Multiple images/ Multiple Configurations, RMON v1/v2, LLDP/LLDP-MED, Flash File System, DDP, NTPv3/v4, Password recovery/encryption, SMTP
Stackable
4 Stacking Ports; Physical stacking - Up to 9 units per stack, Up to 200 Gbps stacking bandwidth, Ring/chain topology support; Virtual stacking - D-Link Single IP Management (SIM), Up to 32 units per virtual stack
Fans
3x Smart fans
Захранване
Optional Redundant Power Supply: DPS-500A, DPS-500DC
Routing
Layer 3 Advanced
Памет (Flash, RAM)
-
Капацитет за маршрутизиране/превключване, Gbps
760 Gbps
Пропускателна способност, Mpps
565.44 Mpps
MAC адреси
32000 MAC address table size
VLAN (брой, стандарти)
802.1Q, 802.1v, Double VLAN (Q-in-Q), Port/MAC-based VLAN, Auto Surveillance/Voice VLAN, VLAN translation, Multicast/Asymmetric/Private/Super VLAN, VLAN Trunking, GVRP - Max. 4K dynamic VLAN groups, VLAN Group: Max. 4K VLAN groups, Max. 1~4094 VIDs
QoS
802.1p Quality of Service (QoS), 8 queues per port, Queue handling (Strict, Weighted Round Robin (WRR), Strict + WRR, Weighted Deficit Round Robin (WDRR)), Bandwidth Control, Congestion Control, Policy Map, Three Color Marker
L2 мрежови стандарти
IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.3x, IEEE 802.1X, IEEE 802.1Q, IEEE 802.1v, IEEE 802.1AX, IEEE 802.1p, IEEE 802.1Qbb, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3ad
L3 мрежови стандарти
Static Route, RIPv1/v2/ng, OSPFv2/v3
IPv6 functionality
IPv6 traffic class, IPv6 flow label, IPv6 Snooping, IPv6 Route Advertisement (RA) Guard, IPv6 ND Inspection
Сигурност
Port Security, Broadcast/Multicast/Unicast Storm Control, D-Link Safeguard Engine, DHCP Server Screening, Dynamic ARP Inspection, IP Source Guard, DHCP Snooping, DHCPv6 Guard, BPDU Attack Protection, DOS Attack Prevention, SSH, SSL, Traffic Segmentation
Размери (Ш, Д, В), mm
441 x 250 x 44 mm
Опция за монтаж
Rackmount
Други
Console Port: RJ-45 port for out-of-band CLI management, Management Port: 10/100/1000BASE-T RJ-45 port for out-of-band IP management, 1x USB 2.0 Type A port
Гаранция, м.
99 месеца
Тегло, кг.
4.2 кг.
