Спецификации
- Суич, типFixed Port
- Общ брой портове54
- Основни портове, тип48xSFP
- Power Over Ethernet (PoE)No
- Uplink портове4x10GE SFP, 2x10GBase-T
- Свободни (10GB) слотовеNo
- УправлениеWeb-based GUI, Command Line Interface (CLI), SNMP, RMON v1/v2, LLDP/LLDP-MED, BootP/DHCP Client, DHCP, Flash File System, D-Link Discover Protocol (DDP), Debug command, NTPv3/v4, Command Logging, Ping/Traceroute for IPv4/IPv6, Password recovery/encryption
- Stackable4 Stacking Ports; Physical stacking: Stacking Lite, Up to 80 Gbps stacking bandwidth, Ring/chain topology support; Virtual stacking: D-Link Single IP Management (SIM), Up to 32 units per virtual stack
- Fans4x Smart fans
- ЗахранванеPower Input: 100 to 240 V AC 50/60 Hz; Max Power Consumption: 95.06 W, Standby - 36.41 W; Optional Redundant Power Supply: DPS-500A
- RoutingLayer 3 Advanced
- Памет (Flash, RAM)Packet Buffer Memory: 4 MB
- Капацитет за маршрутизиране/превключване, Gbps216 Gbps
- Пропускателна способност, Mpps161 Mpps
- MAC адреси16000 MAC address table size
- VLAN (брой, стандарти)VLAN Group: Max. 4K VLAN groups, Max. 1~4094 VIDs; GVRP (Max. 4K dynamic VLAN groups); Double VLAN (Q-in-Q); 802.1Q; Port-based VLAN; 802.1v Protocol-based VLAN; MAC-based VLAN; VLAN translation; Multicast/Asymmetric/Private VLAN; VLAN Trunking;Super VLAN
- QoS802.1p Quality of Service; 8 queues per port; Queue Handling - Strict, Weighted Round Robin (WRR), Strict + WRR, Weighted Deficit Round Robin (WDRR); Policy Map - Remark 802.1p priority, Remark IP precedence/DSCP, Time based QoS; Congestion Control - WRED
- L2 мрежови стандартиIEEE 802.1p, IEEE 802.1X, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1AX, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1v
- L3 мрежови стандартиStatic Route, RIPv1/v2/ng, OSPFv2/v3
- IPv6 functionalityIPv6 traffic class, IPv6 Flow Label, IPv6 Snooping, IPv6 Route Advertisement (RA) Guard, IPv6 ND Inspection
- СигурностBroadcast/Multicast/Unicast Storm Control, D-Link Safeguard Engine, Port Security - Supports up to 64 MAC addresses per port, Dynamic ARP Inspection (DAI), DHCPv6 Guard, IP Source Guard, Duplicate Address Detection (DAD), Traffic Segmentation, SSL, SSH
- Размери (Ш, Д, В), mm440 x 430 x 44 mm
- Опция за монтажRackmount
- Други10/100/1000BASE-T RJ-45 port for out-of-band CLI management, 10/100/1000BASE-T RJ-45 port for out-of-band IP management, 1x USB 2.0 Type A port
- Гаранция, м.99 месеца
- Тегло, кг.6.3 кг.
