Спецификации
- Суич, типFixed Port
- Общ брой портове16
- Основни портове, тип12x10GBase-T
- Power Over Ethernet (PoE)No
- Uplink портове2 dual personality, 2x10GE SFP
- Свободни (10GB) слотовеNo
- УправлениеWeb-based GUI; D-Link Network Assistant Utility; Full CLI; Telnet Server; TFTP Client; Configurable MDI/MDIX; SNMP (Supports v1/v2c/v3); SNMP Trap; Smart Wizard; LLDP; LLDP-MED; System Log; BootP/DHCP Client; SNTP; ICMP v6; IPv4/v6 Dual Stack;Trusted Host
- StackableNo
- Fansyes
- ЗахранванеInternal power supply: 100 to 240 VAC
- RoutingLayer 3 Lite
- Памет (Flash, RAM)-
- Капацитет за маршрутизиране/превключване, Gbps320 Gbps
- Пропускателна способност, Mpps238.08 Mpps
- MAC адреси16000 MAC address table size
- VLAN (брой, стандарти)802.1Q VLAN, Port-based VLAN, 4K VLAN Groups, Configurable VID 1-4094, Voice VLAN, Auto Surveillance VLAN, Asymmetric VLAN
- QoS802.1p; 8 queues per port; Queue Handling - Strict, Weighted Round Robin (WRR), Deficit Round Robin (DRR), Weighted Deficit Round Robin (WDRR), Strict + WDRR; Bandwidth Control - Port-based (Ingress/Egress, min. granularity 64 Kbps)
- L2 мрежови стандартиIEEE 802.3u, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3an, IEEE 802.3ae, IEEE 802.3z, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1X, IEEE 802.1Q, IEEE 802.1p
- L3 мрежови стандартиDefault Route, Static Route: Max. 64 IPv4/Pv6 entries
- IPv6 functionalityIPv6 Traffic Class, IPv6 Flow Label, IPv6 Neighbor Discovery (ND)
- СигурностBroadcast/Multicast/Unicast Storm Control; D-Link Safeguard Engine; DHCP Server Screening; IP-MAC-Port Binding; Traffic Segmentation; SSL (Support v1/v2/v3, Support IPv4/IPv6); DoS Attack Prevention; Port Security; Duplicate Address Detection
- Размери (Ш, Д, В), mm440 x 210 x 44
- Опция за монтажRackmount
- Гаранция, м.99 месеца
- Тегло, кг.4 кг.
