Спецификации
- Суич, типFixed Port
- Общ брой портове52
- Основни портове, тип48x10/100/1000Base-T
- Power Over Ethernet (PoE)No
- Uplink портове2x10GE SFP, 2x10GBase-T
- Свободни (10GB) слотовеNo
- УправлениеWeb-based GUI, Command Line Interface (CLI), Telnet Server/Client for IPv4/IPv6, TFTP Client for IPv4/IPv6, DNS Client for IPv4/IPv6, SNMP, sFlow, RMON v1/v2, DHCP, D-Link Discover Protocol (DDP), NTPv3/v4
- StackablePhysical stacking: 10GBase-T and SFP+, Up to 8 units per stack, Up to 80 Gbps stacking bandwidth, Ring/chain topology support; Virtual stacking: D-Link Single IP Management (SIM), Up to 32 units per virtual stack
- Fansyes
- Захранване100 - 240 VAC; Max. Power Consumption: 51.2 W, Optional Redundant Power Supply: DPS-520
- RoutingLayer 3 Advanced
- Капацитет за маршрутизиране/превключване, Gbps176 Gbps
- Пропускателна способност, Mpps130.95 Mbps
- MAC адресиUp to 16384 entries per device
- VLAN (брой, стандарти)VLAN Group (Max. 4K VLAN groups, Max. 1~4094 VIDs); GVRP - Max. 4K dynamic VLAN groups; Double VLAN (Q-in-Q); Selective Q-in-Q; 802.1Q; Auto Surveillance/Port-based/Voice/MAC-based/Multicast/Subnet-based/Asymmetric/Private VLAN; 802.1v Protocol-based VLAN
- QoS802.1p; 8 queues per port; Queue Handling; Congestion Control; Policy Map; CoS based on: Switch port, Inner/Outer VID, Inner/Outer 802.1p Priority, MAC address, Ether type, IP address, DSCP, ToS/IP preference, Protocol type, TCP/UDP port;Bandwidth Control
- L2 мрежови стандартиIEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3az, IEEE 802.3x, IEEE 802.3ae, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.3ad, IEEE 802.1Q, IEEE 802.1v, IEEE 802.1Qbb, IEEE 802.1p, IEEE 802.1X, IEEE 802.1AX
- L3 мрежови стандартиStatic Route, RIPv1/v2/ng, OSPF: OSPF v2/v3, OSPF passive interface, Stub/NSSA area, Supports Equal-Cost Multi-Path Route (ECMP), Text/MD5 authentication
- IPv6 functionalityIPv4/IPv6 access; Telnet Server/Client; TFTP/DNS Client; Secure FTP Server/Client; Ping/ Traceroute; IPv6 Snooping; IPv6 Route Advertisement (RA) Guard; IPv6 ND Inspection; IPv6 Traffic Class; IPv6 Flow Label
- СигурностPort Security (Supports up to 64 MAC addresses per port), Broadcast/Multicast/Unicast Storm Control, D-Link Safeguard Engine, DHCP Server Screening, IP Source Guard, DHCP/IPv6 Snooping, DAI, ARP Spoofing Prevention, SSL, SSH, BPDU Attack Protection
- Размери (Ш, Д, В), mm441 x 207.4 x 44 mm
- Опция за монтажRackmount
- Гаранция, м.99 месеца
- Тегло, кг.4.07 кг.
