Спецификации
- Суич, типFixed Port
- Общ брой портове28
- Основни портове, тип20xSFP
- Power Over Ethernet (PoE)No
- Uplink портове4 dual personality, 4x10GE SFP
- Свободни (10GB) слотовеNo
- УправлениеWeb-based GUI, Command Line Interface (CLI), Telnet server/client, Command logging, SNMP v1/v2c/v3 (supports IPv4), SNMP Traps, System log, SMTP (supports IPv4), RMON v1/v2, 802.1AB LLDP, Flash file system, Multiple image, D-Link Discovery Protocol (DDP)
- StackablePhysical Stacking: Up to 80 Gbps stacking bandwidth, Up to 9 switches in a stack, Ring/chain topology support; D-Link Single IP Management (SIM): Up to 32 units per virtual stack
- Fans2 x Smart Fan
- ЗахранванеAC Input: 100 to 240 VAC 50/60 Hz, Max Power Consumption: 45.2 W, Redundant Power Supply
- RoutingLayer 3 Lite
- Памет (Flash, RAM)-
- Капацитет за маршрутизиране/превключване, Gbps128 Gbps
- Пропускателна способност, Mpps95.24 Mpps
- MAC адреси16000 MAC address table size
- VLAN (брой, стандарти)VLAN group (Max. 4094 VLAN), Port-based/MAC-based VLAN, GVRP (Max. 255 dynamic VLANs), 802.1v Protocol VLAN, Double VLAN (Port-based/Selective Q-in-Q), 802.1Q tagged VLAN, ISM VLAN, VLAN translation, VLAN trunking, Voice VLAN, Private VLAN
- QoS802.1p; 8 queues per port; Queue Handling: Strict Priority (SP), Weighted Round Robin (WRR), Strict + WRR, Deficit Round Robin (DDR), Weighted Deficit Round Robin (WDRR); Bandwidth control: Port/Flow-based (ingress/egress, min. granularity 64 Kbps)
- L2 мрежови стандартиIEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1AX, IEEE 802.3ad, IEEE 802.1v, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1X, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.1AB
- L3 мрежови стандартиStatic route: 64 IPv4 static routes, 32 IPv6 static routes
- IPv6 functionalityIPv6 Route Advertisement (RA) Guard, IPv6 ND snooping, IPv6 ND inspection, IPv6 traffic class, IPv6 Flow Label, IPv6 Neighbor Discovery (ND)
- СигурностSSH v2, TLS 1.2, Port Security (Up to 6656 MAC addresses per port), Broadcast/multicast/unicast storm control, Traffic segmentation, D-Link Safeguard Engine, DHCP server screening, ARP spoofing prevention, BPDU/DoS attack prevention
- Размери (Ш, Д, В), mm440 x 210 x 44 mm
- Опция за монтажDesktop or 19" Rack Mount (mounting brackets included)
- Гаранция, м.99 месеца
- Тегло, кг.3.4 кг.
