Спецификации
- Суич, типFixed Port
- Общ брой портове52
- Основни портове, тип48x10/100/1000Base-T
- Power Over Ethernet (PoE)No
- Uplink портове4xSFP
- Свободни (10GB) слотовеNo
- УправлениеWeb-based GUI, D-Link Network Assistant Utility, Compact CLI, Telnet Server, TFTP Client, Configurable MDI/MDIX, SNMP v1/v2c/v3, SNMP Trap, Backup/Upgrade firmware, Smart Wizard, Upload/Download Configuration file, RMONv1, Trusted Host, ICMP v6, SNTP
- StackableNo
- FansLow speed: 39.8 dBA, High speed: 49.2 dBA
- ЗахранванеInternal Universal Power Supply: 100 - 240 VAC, 50/60 Hz
- RoutingLayer 2 Only
- Памет (Flash, RAM)-
- Капацитет за маршрутизиране/превключване, Gbps104 Gbps
- Пропускателна способност, Mpps77.4 Mpps
- MAC адреси16000 MAC address table size
- VLAN (брой, стандарти)IEEE 802.1Q; VLAN Group: max. 256 static VLAN groups, max. 4094 VIDs; Asymmetric VLAN; Auto Voice VLAN: max. 10 user defined OUI, max. 8 default OUI; Auto Surveillance VLAN
- QoS802.1p Quality of Service; 8 queues per port; Queue Handling - Strict, Weighted Round Robin (WRR); Bandwidth Control - Port-based (Ingress/Egress, min granularity 10/100/1000 is 64 Kbps); QoS based on: 802.1p Priority Queues, DSCP, ToS, IPv6, TCP/UDP port
- L2 мрежови стандартиIEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1X
- L3 мрежови стандарти-
- IPv6 functionalityIPv6 Ready: Fully IPv6 compatible and ready for enterprise deployment, giving you a head start on the next Internet standards evolution
- СигурностBroadcast/Multicast/Unicast Storm Control, D-Link Safeguard Engine, DHCP Server Screening, IP-MAC-Port Binding (Smart Binding), 802.1X Port-based Access Control, ARP Spoofing Prevention, Traffic Segmentation, SSH v2, SSL, Port Security
- Размери (Ш, Д, В), mm440 x 210 x 44
- Опция за монтажRackmount
- Гаранция, м.99 месеца
- Тегло, кг.4.6 кг.
