Спецификации
- Суич, типFixed port
- Общ брой портове10
- Основни портове, тип8x GE copper ports (10/100/1000 RJ45 Copper ports)
- Power Over Ethernet (PoE)240W budget, IEEE 802.3af, IEEE 802.3at
- Uplink портове2x GE SFP ports (100/1000 SFP ports)
- Свободни (10GB) слотове-
- УправлениеWeb UI, MIB, SmartPort, SNMP, syslog, DHCP server, SPAN session, RSPAN, FSPAN, Express setup, NETCONF, RESTCONF
- Stackable-
- FansConvection cooled
- ЗахранванеRedundant DC input voltage: 9.6 to 60VDC, 48VDC is required for PoE and 54VDC is required for PoE+, Maximum Input current: 5.5A, Power consumption: 32W
- RoutingLayer 3 routing: Inter-VLAN routing, static routing
- Памет (Flash, RAM)DRAM - 2 GB, Flash (User Accessible) - 1.5 GB, Optional: SD card capacity - 4 GB
- Капацитет за маршрутизиране/превключване, GbpsLine rate for all ports and all packet sizes
- MAC адреси8K
- VLAN (брой, стандарти)VLANs: 256, IEEE 802.1q VLAN
- СигурностPort security, 802.1x, DHCP snooping, dynamic ARP inspection, IP source guard, guest VLAN, MAC authentication bypass, storm control,SCP,SSH, SNMPv3, TACACS+, RADIUS server/client, MAC address notification, BPDU guard, SUDI 2099, PACL/RACL/VACL, MACsec-128
- Мрежови стандартиIEEE 802.1D, 802.1p, 802.1q, 802.1s, 802.1w, 802.1x, IEEE 802.1AB LLDP, IEEE 1588v2, 802.3ad, 802.3ah, 802.3, 802.3x, 802.3u, 802.3ab, 802.3z
- Протоколи за индустриална автоматизацияCIP Ethernet/IP, IEEE 1588 PTP v2 (default and power), PROFINET
- Работна температура-40°C to +70°C (40 LFM vented enclosure), -40°C to +60°C (sealed enclosure), -34°C to +75°C (Min. 200 LFM fan or blower-equipped enclosure), +85°C (type tested for 16 hours)
- Размери (Ш, Д, В), mm91 x 135 x 152 mm
- Опция за монтажDIN rail
- Гаранция, м.60 месеца
- Тегло, кг.2.48 кг.
- Други1x RS-232 (via RJ-45), 1x USB Mini Type B, Network Essentials, IPv6 functionality, Dying gasp, SCADA protocol classification - GOOSE messaging, MODBUS TCP/IP
- QoSIngress policing, rate limit, egress queuing and shaping, auto QoS
