Спецификации

Вх.напрежение, V
Range: 200-276V without derating (up to 140-276V with derating); Nominal Voltage: 200–240V
Изх. мощност, VA
3000 VA/2700 W
Брой изводи
6
Тип изводи
8 IEC C13 (10A) sockets + 1 IEC C19 (16A) socket; Input: 1 IEC C20 (16A)
Защити
ABM or Temperature compensated charging method, automatic battery test, deep discharge protection, automatic EBM recognition.
Технология
On-line double-conversion with Power Factor Correction (PFC) system
Гаранция, м.
24 месеца
Тегло, кг.
36 кг.
Други
1 USB port + 1 serial RS232 port + 1 mini-terminal block for Remote Power Off + 1 mini-terminal block for Output relay; Communication Slot: 1 slot for Network-M2, Network-MS, ModBus-MS or Relay-MS cards
Стандарти
Safety markings: IEC/EN 62040-1, UL 1778, CSA 22.2; EMC Markings: IEC/EN 62040 -2 , FCC Class B, CISPR22 Class B
