Спецификации

Вх.напрежение, V
Range: 190-276V without derating (up to 120-276V with derating); Nominal Voltage: 200–240V
Изх. мощност, VA
1000 VA/ /900 W
Брой изводи
6
Тип изводи
(6) IEC-320-C13; Input: IEC-320-C14
Защити
ABM or Temperature compensated charging method, automatic battery test, deep discharge protection, automatic EBM recognition.
Технология
On-line double-conversion with Power Factor Correction (PFC) system
Гаранция, м.
24 месеца
Тегло, кг.
15.7 кг.
Други
1 USB port + 1 serial RS232 port + 1 mini-terminal block for Remote Power Off + 1 mini-terminal block for Output relay; Communication Slot: 1 slot for Network-M2, Network-MS, ModBus-MS or Relay-MS cards
Стандарти
Safety markings: IEC/EN 62040-1, UL 1778, CSA 22.2; EMC Markings: IEC/EN 62040 -2 , FCC Class B, CISPR22 Class B
