Спецификации
- Суич, типFixed Port
- Общ брой портове26
- Основни портове, тип24x10/100/1000Base-T
- Power Over Ethernet (PoE)IEEE 802.3af, IEEE 802.3at PoE Standard; PoE: Ports 1 to 24; Max. Port Power: 30 W; PoE Power Budget: 370 W
- Uplink портове2x10/100/1000Base-T
- Свободни (10GB) слотовеNo
- УправлениеRemote management via Hik-Partner Pro; Management via Hik-Central Pro; Device management via web; DHCP Client, Port mirroring
- StackableNo
- FansFanless design
- Захранване100~240 V AC, 50/60 Hz, Max. 6.3 A; Max. Power Consumption: 400 W
- RoutingLayer 2 Only
- Памет (Flash, RAM)-
- Капацитет за маршрутизиране/превключване, Gbps56 Gbps
- Пропускателна способност, Mpps41.66 Mpps
- MAC адреси8000 MAC address table size
- VLAN (брой, стандарти)VLAN is used for network scale planning and network health improvement; Support 802.1Q; Configurable VLAN ID from 1-4094; Support Trunk, Access port mode; Support Max. 32 VLAN
- QoSQoS is used to allocate bandwidth to different services so as to provide end-to-end service quality assurance. Support port-based priority configuration, Support SP and WRR priority scheduling modes
- L2 мрежови стандартиIEEE 802.1Q, IEEE 802.3af, IEEE 802.3at, IEEE 802.1D, IEEE 802.1w, IEEE 802.1ab, IEEE 802.3az
- L3 мрежови стандарти-
- IPv6 functionality-
- Сигурност6 kV Surge Protection, STP/RSTP loop prevention, cable detection to locate failure, DHCP snooping
- Размери (Ш, Д, В), mm440.0 x 220.8 x 44.0 mm
- Опция за монтажRackmount
- Гаранция, м.24 месеца
- Тегло, кг.3.3 кг.
