HikVision 24 Port Gigabit Smart POE Switch, 24 x Gigabit PoE port,1 x Gigabit RJ45 port, 1 x...

HikVision 24 Port Gigabit Smart POE Switch, 24 x Gigabit... - 0

Спецификации

Суич, тип
Fixed Port
Общ брой портове
26
Основни портове, тип
24x10/100/1000Base-T
Power Over Ethernet (PoE)
IEEE 802.3af, IEEE 802.3at PoE Standard; PoE: Ports 1 to 24; Max. Port Power: 30 W; PoE Power Budget: 370 W
Uplink портове
2x10/100/1000Base-T
Свободни (10GB) слотове
No
Управление
Remote management via Hik-Partner Pro; Management via Hik-Central Pro; Device management via web; DHCP Client, Port mirroring
Stackable
No
Fans
Fanless design
Захранване
100~240 V AC, 50/60 Hz, Max. 6.3 A; Max. Power Consumption: 400 W
Routing
Layer 2 Only
Памет (Flash, RAM)
-
Капацитет за маршрутизиране/превключване, Gbps
56 Gbps
Пропускателна способност, Mpps
41.66 Mpps
MAC адреси
8000 MAC address table size
VLAN (брой, стандарти)
VLAN is used for network scale planning and network health improvement; Support 802.1Q; Configurable VLAN ID from 1-4094; Support Trunk, Access port mode; Support Max. 32 VLAN
QoS
QoS is used to allocate bandwidth to different services so as to provide end-to-end service quality assurance. Support port-based priority configuration, Support SP and WRR priority scheduling modes
L2 мрежови стандарти
IEEE 802.1Q, IEEE 802.3af, IEEE 802.3at, IEEE 802.1D, IEEE 802.1w, IEEE 802.1ab, IEEE 802.3az
L3 мрежови стандарти
-
IPv6 functionality
-
Сигурност
6 kV Surge Protection, STP/RSTP loop prevention, cable detection to locate failure, DHCP snooping
Размери (Ш, Д, В), mm
440.0 x 220.8 x 44.0 mm
Опция за монтаж
Rackmount
Гаранция, м.
24 месеца
Тегло, кг.
3.3 кг.
