Задължителен е минимум 3-годишен лиценз DNA Essentials!
Спецификации
- Суич, типFixed Port
- Общ брой портове24
- Основни портове, тип24x10/100/1000Base-T
- Power Over Ethernet (PoE)IEEE 802.3at PoE+ Standard. Available PoE Power: 445W
- Uplink портове0
- Свободни (10GB) слотове1 open module slot: Support four optional uplink modules (C9300-NM-4G, C9300-NM-8X, C9300-NM-2Q, C9300-NM-4M). Also supported 3850 network modules (C3850-NM-4-1G, C3850-NM-2-10G, C3850-NM-4-10G).
- УправлениеSNMPv1, SNMPv2c, and SNMPv3; RMON I and II standards; Internet Group Management Protocol (IGMP); CLI; TCP; UDP
- StackableCisco StackWise-480 stacking ports: copper-based Cisco StackWise cabling
- FansThree field-replaceable fans
- ЗахранванеDual redundant power supplies, Default power supply: PWR-C1-715WAC
- RoutingLayer 3 Advanced
- Памет (Flash, RAM)Flash memory: 16 GB; RAM: 8 GB DRAM
- Капацитет за маршрутизиране/превключване, Gbps208 Gbps
- Пропускателна способност, Mpps154.76 Mpps
- MAC адреси32000 MAC address table size
- VLAN (брой, стандарти)VLAN IDs: 4000; IEEE 802.1Q VLAN
- QoSGranular wireless bandwidth management and fair sharing,802.1p Class of Service (CoS) and Differentiated Services Code Point (DSCP) field classification,Shaped Round Robin (SRR) scheduling,Committed Information Rate (CIR), and eight egress queues per port
- L2 мрежови стандартиIEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3bz, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.1x-Rev, IEEE 802.3x, IEEE 802.1AE
- L3 мрежови стандартиIP unicast routing protocols: Static, Routing Information Protocol Version 1 [RIPv1], and RIPv2, RIPng, Open Shortest Path First [OSPF]
- IPv6 functionalityIPv6 routing; IPv6 addressing; Dual-stack support for IPv4/IPv6 and dynamic hardware forwarding table allocations, for ease of IPv4-to-IPv6 migration; IPv6 support in hardware, providing wire-rate forwarding for IPv6 networks
- СигурностEncrypted Traffic Analytics (ETA), AES-256 MACsec encryption, Trustworthy systems built with Cisco Trust Anchor Technologies (Image signing, Secure Boot, Cisco Trust Anchor module)
- Размери (Ш, Д, В), mm445 x 445 x 44
- Опция за монтажRackmount
- ДругиЗадължителен е минимум 3-годишен лиценз DNA Essentials.
- Гаранция, м.99 месеца
- Тегло, кг.8 кг.
